Hi :), welcome to the 7th part of my tutorial on how to create offline\online map app for android.

Series outline:

• Series aim.
• Theory you need to know.
• App design.
• Writing a TilesManager.
• Writing a TilesProvider.
• Seeing results with MapView.
• Adding web support
• Creating MapView in XML

______________________________________

So once again it’s an unplanned tutorial and it’s about maps 😀 .

The thing is that I got a number of comments asking about how to create the mapView in XML instead of creating it in java code, what we’ll achieve here is:

• Make the mapView creatable from XML.
• Assign a zoom level to the mapView in XML.
• Adding a position marker (drawable) to the mapView from XML.
• Add ZoomControls to the layout containing the mapView in XML.

Here’s how the final result should look like:

MapApp with ZoomControls

And just a note before you continue reading: you can add the mapView in XML like any other view, one difference though is that you cannot rely on using wrap_content in the view, since there’s nothing to wrap (something like text in a button for example) but this is not end of the world, you can either using fill_parent or use 0dip with android:layout_weight, only then the mapView will play nicely with other views :).

So either use a RelativeLayout and put your mapView and other views in it, or use LinearLayout and supply weight values for your views.

So if you’re still reading this please download the source code (along with the empty database) from MapApp 6 : Web Support since I’ll be building on the code from that tutorial. Just please remember to put the database World.sqlitedb in the folder /mapapp/ on the sdcard.

The steps we will have to do are Read more…

Hello, welcome to the 6th part of my tutorial on how to create an offline? map app without using Google™ API, okay this time it’s no longer offline :D! now the app will be able to download tiles from the internet :D!.

Series outline:

• Series aim.
• Theory you need to know.
• App design.
• Writing a TilesManager.
• Writing a TilesProvider.
• Seeing results with MapView.
• Adding web support
• Creating MapView in XML.
• Extra: Fuchs Maps.

______________________________________

At first I planned on writing some basic tips about web tiles server support but then I realized that implementing web support needs some work and code organizing since multi threading becomes a must!. You cannot wait for the tiles to be downloaded in the UI thread!.

We will assume that you have a running tiles server that provides you with tiles you specify using a custom url like this:

http://myserver.com/?x=1&y=3&z=0
or

When we want a specific tile we first search if we have it in our memory cache, if we don’t then we search in the database, if we fail to find it then we download it from the internet.
It’s kind of similar to multi cache levels in a cpu, if one level fails it gets the requested data from the next level, when data found in a certain level all lower levels save a copy of the data since it’s highly likely to be asked for the same data in the near future.
In our case when you don’t have a tile in memory or in database you get it from the web server and then save it in the database and keep it in memory for later use.

We’ve already implemented the first two levels (Memory & database) in the tutorial part 4, the TilesProvider class covered them both. but we didn’t have any threading manipulation, this time we have to be very careful about threading stuff. We will implement new classes and modify some of the old ones, the changed lines in existing classes will be highlighted in grey. Also note that if you’re using Eclipse as your IDE you can always count on the keyboard shortcut Ctrl+Shift+O to automatically import the right packages.


We will add three source files to our project in a new package called com.mapapp.tileManagement.web

Let’s first implement the class TileDownloadTask, this class handles Read more…

Welcome to the fifth and final part of my tutorial on how to create a map app for Android without using Google™ APIs :).

Series outline:

• Series aim.
• Theory you need to know.
• App design.
• Writing a TilesManager.
• Writing a TilesProvider.
• Seeing results with MapView.
• Adding web support.
• Creating MapView in XML.
• Extra: Fuchs Maps.

______________________________________

So up until now we didn’t see any results :(, this is where everything changes :D.

In this part we’ll write three classes:

MapView: a custom view to render and manipulate the map.

MapAppActivity: the main (and only) activity for the app, mainly creates the MapView and handles activity state changes.

MapViewLocationListener : An extended LocationListener that knows how to deal with a MapView.

MapView:

First thing you should know about this view is Read more…
